Product Details
Place of Origin: CHINA
Brand Name: ORGINAL
Model Number: A-393BT
Payment & Shipping Terms
Minimum Order Quantity: 1SET
Price: Negotiable
Packaging Details: wooden pallet,20 feet container can load 1set
Delivery Time: 90 days
Supply Ability: 5SETS PER MONTH
Warranty: |
12months |
Cutting Length: |
420(90)-4500mm/6000mm(500 Blades) |
Motor Power: |
2.8KW |
Warranty: |
12months |
Cutting Length: |
420(90)-4500mm/6000mm(500 Blades) |
Motor Power: |
2.8KW |
A-393BT Angle Double-head cutting saw
Machine Features:
It is used for the aluminum hold milling. Use the different size of hole mould copy milling 1:1 onto the products. Or use the limited block to mill the hole.
| Machine parameters | |
| 1. Working bench size(L×W) | 650×180mm |
| 2. Max. right & left moving distance of mill blade holder | 255mm |
| 3. Max. front & back moving distance of mill blade holder | 110mm |
| 4. Max. right & left milling | 224mm |
| 5. Max. front & back milling | 100mm |
| 6. Max. up and down moving distance of mill blade holder | 170mm |
| 7. Milling blade diameter | Max. Φ8mm min. Φ5mm |
| 8. Milling blade running speed | 1000r/min |
| 9. Motor power | 1.5kw |
| 10. Motor running speed | 2830r/min |
| 11. Air press of pressing cylinder | 0.6～0.8MPa |
| 12. Machine dimension(L×W×H) | 770(including material frame 2250)×720×1500mm |
