Toilet And Kitchen Towel Folding Machine Fast Speed 250m / Min 1 Year Guarantee

Certification
Good quality Facial Tissue Production Line for sales
The delivery time is quick, and very important: the products always sent match the order. I trust them because i've never been disapointed with them.

—— Jerry

This mutual cooperation last for about 4 years,and must admit the service they provide is aboved expected. Our cooperation will last for many years.

—— Rose

I'm Online Chat Now

Toilet And Kitchen Towel Folding Machine Fast Speed 250m / Min 1 Year Guarantee

China Toilet And Kitchen Towel Folding Machine Fast Speed 250m / Min 1 Year Guarantee supplier
Toilet And Kitchen Towel Folding Machine Fast Speed 250m / Min 1 Year Guarantee supplier Toilet And Kitchen Towel Folding Machine Fast Speed 250m / Min 1 Year Guarantee supplier

Large Image :  Toilet And Kitchen Towel Folding Machine Fast Speed 250m / Min 1 Year Guarantee

Product Details:

Place of Origin: CHINA
Brand Name: ORGINAL
Model Number: FS-OR-250-2900

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: Negotiable
Packaging Details: wooden pallet,20 feet container can load 1set
Delivery Time: 60 days
Supply Ability: 3 sets per month
Contact Now
Detailed Product Description
Embossing: Steel To Steel Voltage: 380V,50Hz
Vacuum Pump: Root Vacuum Pump Backstand: 1-3sets
Guarantee: 1 Year Glue Lamination: With Glue Lamination System
GSM: 13-25GSM/PLY Power: 15KW
Maximum Jumbo Roll Width: 2950mm

One Machine can do Toilet and Kitchen Towel Lamination Tissue products



FS-OR-250-2900 Toilet /Kitchen Towel Rewinding Machine



Parameters:

MODLE 1575 1760 2200 2500 2800 2900 3000
Max.Jumbo roll width(mm) 1750 2000 2150 2400 2750 2850 2950
Finished product diameter(mm) Ф60-150
Finished product core inner diameter(mm) Ф32-50
Jumbo roll diameter(mm) ≤Ф1200(other size should be ordered)
Jumbo roll core inner diameter(mm) Ф76.2(other size should be ordered)
Perforating size(mm) 110mm(other size should be ordered,4PCS spiral perforating blade)
Machine speed 250m/min
Parameter setting SIEMENS touch screen
PLC control SIEMENS PLC
backstand 1-4sets(should be ordered)
Air pressure 0.8Mpa(user supply)
Power 13.5-35Kw,380V,50Hz(base on the model)
Option
Embossing unit Single,double embossing/steel to steel/steel to rubber/steel to paper(should be ordered)
backstand 1-4 sets(should be ordered)
Transmission Separating motor driving/timming belt transmission/chain and chain wheel transmission
Lamination unit Should be ordered
Edge embossing unit Air bag type(should be ordered)
Calendering unit Steel to steel/steel to rubber(should be ordered)
