Kitchen Towel / Toilet Paper Production Line 2600mm Mitsubishi PLC Control

China Kitchen Towel  /  Toilet Paper Production Line  2600mm  Mitsubishi PLC Control supplier
Kitchen Towel  /  Toilet Paper Production Line  2600mm  Mitsubishi PLC Control supplier Kitchen Towel  /  Toilet Paper Production Line  2600mm  Mitsubishi PLC Control supplier Kitchen Towel  /  Toilet Paper Production Line  2600mm  Mitsubishi PLC Control supplier Kitchen Towel  /  Toilet Paper Production Line  2600mm  Mitsubishi PLC Control supplier

Large Image :  Kitchen Towel / Toilet Paper Production Line 2600mm Mitsubishi PLC Control

Product Details:

Place of Origin: CHINA
Brand Name: ORGINAL
Model Number: DMFJ-2600//3000A

Payment & Shipping Terms:

Minimum Order Quantity: 1SEST
Price: Negotiable
Packaging Details: wooden pallet,2*40feet container can load 1 set
Delivery Time: 90 working days after receipt deposit
Supply Ability: 1set per month
Contact Now
Detailed Product Description
Running: Start-Stop Production Line Speed: 220meter/min
Capacity: Depends On Your Jumbo Roll Width Voltage: 380V,50Hz
Servo Motor: MITSUBISHI PLC: MITSUBISHI
Touch Screen: MITSUBISHI Warranty: 1 Year
After-sales Service Provided: Engineers Available To Service Machinery Overseas

JRT AND Toilet Two Used Machine 2600mm Kitchen Towel Fully Automatic Production Line



This is our video link :











DMFJ-2600(3000) Fully Automatic Productino Line



Features:



1. High speed:220m/min

2. Can do toilet .JRT in one machine , the glue lamination systme is for optional

4. MITSUBISHI PLC control makes work steadily

5. MITSUBISHI touch screen setting easy to change parameters

7. Separating motor driving

8. MITSUBISHI servo motor driving discharge rolls

9. Accumulator device

10. 2lanes high speed log saw cutter





MODLE 2600 3000
Max.Jumbo roll width(mm) 2550 2950
Capacity 5 tons/day 7 tons/day
Finished product diameter(mm) Ф70-300
Finished product core inner diameter(mm) Ф35-80
Jumbo roll diameter(mm) ≤Ф1500(other size should be ordered)
Jumbo roll core inner diameter(mm) Ф76.2(other size should be ordered)
Perforating size(mm) 110mm(other size should be ordered,4PCS spiral perforating blade)
Machine speed 22m/min
Parameter setting MITSUBISHI touch screen
PLC control MITSUBISHI PLC
backstand 1-6sets(should be ordered)
Air pressure 0.8Mpa(user supply)
Power 15/25Kw,380V,50Hz(base on the model)
Option
Embossing unit Single,double embossing/steel to steel/steel to rubber/steel to paper(should be ordered)
Backstand 1-6 sets(should be ordered)
Jumbo roll loading Pneumatic loader/elevator(should be ordered)
Lamination unit Point to point or glue for nest(should be ordered)
Core or coreless unit Should be ordered
Core winding machine Should be ordered
Automatic core feeding device 300-600PCS storage(should be ordered)
Edge embossing unit Air bag type(should be ordered)
Calendering unit Steel to steel/steel to rubber(should be ordered)
Accumulator 110-210rolls type(should be ordered)
Log saw cutter 2 lanes log saw cutter(should be ordered)
