Small Handky Pocket Tissue Machine With Automatic Folding Division 5.5KW
Small Handky Pocket Tissue Machine With Automatic Folding Division 5.5KW
Features Gallery Product Description Request A Quote
Basic Infomation
Place of Origin: CHINA
Brand Name: ORGINAL
Model Number: HP-1L/2L
High Light:

tissue paper manufacturing machine


tissue making equipment

Payment & Shipping Terms
Packaging Details: wooden pallet,20 feet container can load 4sets
Delivery Time: 45days
Supply Ability: 4sets per month
Color: Blue And White
Counting: Automatic Counting
Separating: Automatic Separating
Automatic Type: Full Automatic
Voltage: 380V ,50Hz
High Speed: 700pcs/min
Voltage: 380V
After-sales Service Provided: Online Support
Power(w): 5.5KW
Warranty: 12months
Product Description

High Speed Mini Handky Pocket Tissue Folding Machine with automatic folding division



HP-1L/2L Automatic pocket tissue folding machine





  • Automatic counting
  • Automatic separating
  • Touch screen parameters setting
  • Connect the packing machine easily
  • High speed:700pcs/min


Model HP-1L/2L
Max.Jumbo roll width 200-201mm
Max.jumbo roll diameter 1500mm
Finished product size (50-54)*(72/102)mm should be chosen
Embossing unit Steel to rubber/steel to paper/steel to steel(option)
Vacuum pump 7.5Kw,380V,50Hz
Counting Automatic counting,6/8/10/12pcs,setting on touch screen
Parameter setting Touch screen
Main power 1.5Kw,380V,50Hz
Working speed 600-650pcs/min
Air pressure 0.8Mpa
Machine size 2380*750*1570mm
