Product Details
Place of Origin: CHINA
Brand Name: ORGINAL
Model Number: XY-BR-291
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: Negotiable
Packaging Details: wooden pallet,1*20feet container can load 1set
Delivery Time: 60 days
Supply Ability: 3 sets per month
High Speed: |
100PCS/min |
Paper GSM: |
18-25 |
Jumbo Roll Width: |
380mm |
Folded Type: |
1/4 |
Machine Weight: |
3000Kg |
Place Of Origin: |
China(Mainland) |
High Speed: |
100PCS/min |
Paper GSM: |
18-25 |
Jumbo Roll Width: |
380mm |
Folded Type: |
1/4 |
Machine Weight: |
3000Kg |
Place Of Origin: |
China(Mainland) |
Main technical data
1. Production speed:80-100pcs/min
2. Specifiction of raw material:18-25g/m2
3. Size of raw materail:1000×380mm
4. Power :7.5kw (380V 50Hz)
5. Overall dimension(mm):4500×700×1700(L×W×H)
6. Weight:3 T
The quality of machine
1. Knife tool can use 40 million pcs ( per 5 million pcs mill the knife once)
2. All transmission parts are processed by special steel, they are resist pressure and toughness.
3. Adopt China name-brand Zhengtai electricity
4. Adopt China name-brand Haerbin bearing.
Specification of raw material:
1. The width of raw material: 380mm
2. The diameter of raw material: 700mm-1000mm
3. The thickness of raw material : 18g/,m２-25g/ m２
4. The diameter of core: 76.2mm
