Product Details
Place of Origin: CHINA
Brand Name: ORGINAL
Model Number: HT210/215/225
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: Negotiable
Packaging Details: wooden pallet,20 feet container can load 1set
Delivery Time: 60 days
Supply Ability: 3 sets per month
Folding Type: |
Z Folded |
Embossing: |
Steel To Steel |
Speed: |
800-1000pcs/min/lane |
Voltage: |
380V,50Hz |
Vacuum Pump: |
Root Vacuum Pump |
Backstand: |
1-2sets |
Folding Type: |
Z Folded |
Embossing: |
Steel To Steel |
Speed: |
800-1000pcs/min/lane |
Voltage: |
380V,50Hz |
Vacuum Pump: |
Root Vacuum Pump |
Backstand: |
1-2sets |
HT210/215/225 N Folded Hand Towel Folding Machine
Features:
Parameters:
| MODEL | 3T | 4T | 5T | 6T |
| Max. Width of jumbo roll | 630mm | 840mm | 1050mm | 1260mm |
| Slitting knife | 3sets in back and front | 4sets in back and front | 5sets in back and front | 6sets in back and front |
| Vacuum pump | 11Kw | 11Kw | 15kw | 18.5kw |
| Main driving motor powe | 4kw | 4kw | 5.5kw | 5.5kw |
| Machine size | 6×1.8×1.9m | 6×2×1.9m | 6×2.3×1.9m | 6×2.5×1.9m |
| Machine weight | 3500kg | 4500kg | 5500kg | 6500kg |
| Machine speed | 500-1000 sheet/min/lane | |||
| Max.diameter of jumbo roll | Ф1200mm(other sizes can be ordered) | |||
| Inner diameter of jumbo roll | Ф76.2mm(other sizes can be ordered) | |||
| Bankstand | 2-6 jumbo rolls (should be ordered) | |||
| Embossing unit | Steel to rubber,steel to paper,steel to steel(should be ordered) | |||
| Lamination unit | Should be option | |||
| Edge embossing unit | Air bag type,bearing pattern(should be ordered) | |||
| Air pressure | 0.8Mpa(user supplied) | |||
