Touch Screen Toilet Paper Production Line / Toilet Paper Rewinder

Product Details

Place of Origin: CHINA

Brand Name: ORGINAL

Model Number: ZE-MZQ-III-E250-2600

Payment & Shipping Terms

Minimum Order Quantity: 1SET

Price: Negotiable

Packaging Details: wooden case,20feet container can load 1set

Delivery Time: 30days

Supply Ability: 3SETS PER MONTH

Get Best Price
Highlight:

toilet roll making machine

,

toilet tissue making machine

Paper Gsm:
13gsm
Separating Driving:
Separating Motor Driving
Backstand Adding:
Easy To Add Backstand
Voltage:
380V
PLC:
SIEMENS PLC
Embossing:
Steel To Rubber Embossing Unit
Production Speed:
200meters/min
Condition:
New
Warranty:
12 MONTH
After-sales Service Provided:
Engineers Available To Service Machinery Overseas
Paper Gsm:
13gsm
Separating Driving:
Separating Motor Driving
Backstand Adding:
Easy To Add Backstand
Voltage:
380V
PLC:
SIEMENS PLC
Embossing:
Steel To Rubber Embossing Unit
Production Speed:
200meters/min
Condition:
New
Warranty:
12 MONTH
After-sales Service Provided:
Engineers Available To Service Machinery Overseas
Touch Screen Toilet Paper Production Line / Toilet Paper Rewinder

Toilet Paper Rewinding Machine with 250m/ Min High Speed can produce JRT and Toilet



ZE-MZQ-III-E250-2600  High speed toilet paper rewinding machine

MODLE 1575 1760 2200 2500 2800 2900 3000
Max.Jumbo roll width(mm) 1750 2000 2150 2400 2750 2850 2950
Finished product diameter(mm) Ф60-150
Finished product core inner diameter(mm) Ф32-50
Jumbo roll diameter(mm) ≤Ф1200(other size should be ordered)
Jumbo roll core inner diameter(mm) Ф76.2(other size should be ordered)
Perforating size(mm) 110mm(other size should be ordered,4PCS spiral perforating blade)
Machine speed 250m/min
Parameter setting SIEMENS touch screen
PLC control SIEMENS PLC
backstand 1-4sets(should be ordered)
Air pressure 0.8Mpa(user supply)
Power 13.5-35Kw,380V,50Hz(base on the model)
Option
Embossing unit Single,double embossing/steel to steel/steel to rubber/steel to paper(should be ordered)
backstand 1-4 sets(should be ordered)
Transmission Separating motor driving/timming belt transmission/chain and chain wheel transmission
Core or coreless unit Should be ordered
Edge embossing unit Air bag type(should be ordered)
Calendering unit Steel to steel/steel to rubber(should be ordered)
