65mm Hydraulic Aluminium Window Cutting Machine Door Frame Punching
65mm Hydraulic Aluminium Window Cutting Machine Door Frame Punching
Features Gallery Product Description Request A Quote
Basic Infomation
Place of Origin: CHINA
Brand Name: ORGINAL
Model Number: A-333F
High Light:

65mm Aluminum Window Cutting Machine


2840r/min Aluminum Window Cutting Machine

Payment & Shipping Terms
Packaging Details: wooden pallet,20 feet container can load 1set
Delivery Time: 90 days
Supply Ability: 5SETS PER MONTH
Warranty: 12months
Milling Blade Running Speed: 2840r/min
Max. Working: 65mm
Product Description

A-333FA Hydraulic Type Aluminum Windows/Door frame Punching Machine


Machine Features:

1.The machine will punch 2PCS aluminum which already cut 45°into 90°.

   2.Base on the frame angle, machine adopts 4 points punching design, so that the punching points are more strongly. Because of the design, we can use it for thermal insulation material, door, window, and ultra-thick curtain angle punching.

Machine parameters
1.Power of oil pump motor 5Hp
2.Pressure of oil pump 20Mpa
3.Air pressure 0.6~0.7Mpa
4.Max. working 65mm
5.Max.working thrust 12000kg
6.Punching position adjust range 8~270mm
7.Machine weight 900kg
8.Machine dimension(L×W×H) 1200×1100×1750mm
9. Air consumption 30L/min
